West Gym AV Guide

Simple setup. Clean shutdown.

Follow each section in order for wireless microphones, HDMI audio, and projectors.

Start here

Read your section before turning anything on.

Choose the guide that matches what you are using. The order matters, especially when connecting a computer and powering the projectors.

Wireless microphones

Audio
01

Check the microphone name

Add batteries, turn on the microphone, and read the name on its screen. Turn on only the matching receiver.

The two Sennheiser wireless microphone receiver boxes in the West Gym equipment rack

Left receiver: Gym 1. Right receiver: Gym 2. Turn on only the receiver that matches your microphone.

Left receiverGym 1
Right receiverGym 2

Never turn on both receiver boxes when you are using only one microphone. This can cause a loud, intermittent noise.

02

Shut down the receiver in this order

Use the exact sequence below. Wait for the receiver to turn off, then turn off the microphone and return the microphone and batteries.

Step 1Press power
Step 2Press up arrow
Step 3Press set
Step 4Hold power

HDMI audio & projectors

Video
01

Request HDMI audio in advance

Request HDMI audio pass-through at least two weekdays before your event. Any media you use must also follow Rancho’s Media Guidelines.

Request HDMI audio
02

Connect the computer before the projectors

Plug in the computer first, then choose HDMI 2 SDI 4K as the display. If you need help setting up the external display, use the guide for your computer.

03

Turn on the projectors

Find the projector remote in the drawer. Stand in front of each projector, point the remote at it, and press power. A flashing green light means the projector is warming up.

Before you leave

Finish the shutdown.

Complete every item. Save the Production Support number before your event so help is easy to reach.

✓

Receiver is off

✓

Wireless mic is off

✓

Projectors are off

✓

Mics and batteries are returned

✓

Production Support is saved

Production support

Troubleshoot first. Then contact Production.

Please complete the steps below before calling or texting. Follow the West Gym AV instructions on this page and check the items that apply to your issue.

Before you contact us

  1. For computer playback problems, fully quit and reopen the software. Restart the computer if the problem remains.
  2. Check the HDMI connection. Follow the setup order in this guide: connect the computer before powering the projectors, and select HDMI 2 SDI 4K as the display.
  3. Confirm each projector is powered on with the remote. A flashing green light means it is warming up. Allow startup to finish.
  4. For a microphone problem, check the batteries and the name on its screen. Turn on only the matching receiver: left = Gym 1; right = Gym 2. Never power both receivers when using only one microphone.
  5. If HDMI audio is missing, confirm that audio pass-through was requested at least two weekdays before your event.
  6. Test again after each change. Note whether the problem affects microphones, HDMI audio, projectors, or more than one item.

If the system still does not work after these checks, call or text Production. Tell us you are using West Gym AV, what you connected, what you already tried, and what is not working.

Important before you call

If the AI assistant answers, answer every single question it asks.

If a Production team member cannot answer, the AI assistant will answer the call. Do not skip questions or end the call before the assistant finishes. Your answers give Production the information needed to understand the problem, see what you already tried, and help you faster when a team member becomes available.

Support may not be immediately available outside Rancho business hours. After-hours requests may wait until the next Rancho business day.
